MAN Raw Water Pump 51065006500
Exploded view. Numbers match the components list below.
- Manufacturer
- MAN
- Also written as
- 51.06500-6500, 51.06500.6500
- Engine model
- MAN D2840 LE401, MAN D2842 LE400and 12 more
- Weight
- 20 kg
- Dimensions
- 250 × 305 × 250 mm
- Country of origin
- Germany
- Condition
- New
About this part
Genuine MAN raw water pump, type KZ 160-IL, for the D-Series including the D2840, D2842 and D2848. Where a pump carries its own manufacturer's type designation alongside the MAN part number, that designation is worth recording in the engine's file. Raw water pumps on marine diesels are frequently bought in by the engine builder from a pump specialist, which means service parts and rebuild kits may be available under the pump maker's numbering as well as under MAN's — useful when a part is on long lead time through one channel and on a shelf through the other. Note the type plate before the pump goes back on, since it is usually unreadable once installed. Photographing it while the pump is on the bench is the version of that record most likely to survive.
Supplied new, in the manufacturer’s packaging, with our warranty of up to 24 months.
Engines this part fits
Components of this assembly
| Pos. | Part number | Name | Qty |
|---|---|---|---|
| 1 | 51065006500 | raw water pump KZ 160-IL | 1 |
| 2 | 51065010240 | water pump housing | 1 |
| 3 | 51065060102 | Impeller | 1 |
| 4 | 51065400021 | intermediate piece | 1 |
| 5 | 51065120034 | gear carrier | 1 |
| 6 | 51065050068 | water pump shaft | 1 |
| 7 | 51917010797 | spacer bush ST35 | 1 |
| 8 | 51906850038 | tensioning nut - CUSN12 | 1 |
| 9 | 51065206015 | Axial face seal | 1 |
| 10 | 51965010472 | radial shaft seal 20X52X7 | 1 |
| 11 | 06569364150 | O-ring 160X3N-FPM1-70-GN | 1 |
| 12 | 06561900712 | seal A18X22-CU | 2 |
| 12 | 06566310237 | seal 18,3X26X1,5-ST/FKM1-80 with elastomer lip | 2 |
| 13 | 06561900736 | seal A33X39-CU | 1 |
| 14 | 06314890087 | ball bearing | 1 |
| 15 | 51934100016 | ball bearing 6304-2RSC3 | 1 |
| 16 | 06290704508 | key A6X6X20-ST60-2K | 1 |
| 17 | 06292000104 | circlip 20X1,20 | 1 |
| 18 | 06290200131 | circlip 52X2,00-ZNPHR5F | 2 |
| 19 | 06080490024 | drain plug M18X1,5-A2 | 2 |
| 20 | 06080490001 | drain plug G1A-A2 | 1 |
| 21 | 06062250706 | stud M8X25-8.8 | 6 |
| 22 | 06110951105 | hex lock nut M8-8-MAN183-B4 | 6 |
| 23 | 06151142131 | shim ring 42X52X1-ST2K50 | 1 |
| 24 | 06151140431 | shim ring 42X52X0,5-ST2K50 | 3 |
| 25 | 06151140131 | shim ring 42X52X0,1-ST2K50-BK | 5 |
