MAN Raw Water Pump 51065007040
Exploded view. Numbers match the components list below.
- Manufacturer
- MAN
- Also written as
- 51.06500-7040, 51.06500.7040
- Engine model
- MAN D2866 E, MAN D2866 LEand 8 more
- Weight
- 14 kg
- Dimensions
- 170 × 160 × 300 mm
- Country of origin
- Germany
- Condition
- New
About this part
Genuine MAN raw water pump for the D2866. Fitting a flexible impeller is a small job with a detail that matters: the vanes must be bent in the direction the pump turns as the impeller goes in, not against it. An impeller installed with its vanes trailing the wrong way works initially and then tears, usually within hours rather than minutes, and the resulting failure looks identical to an ordinary impeller breakup. Use a smear of glycerine or silicone grease rather than a petroleum-based lubricant, since the neoprene the vanes are made from softens on contact with oil or diesel. Turn the pump by hand in its running direction as the impeller is pressed home. An impeller fitted correctly and lubricated properly is one of the few marine jobs where doing it right takes no longer than doing it wrong.
Supplied new, in the manufacturer’s packaging, with our warranty of up to 24 months.
Engines this part fits
Components of this assembly
| Pos. | Part number | Name | Qty |
|---|---|---|---|
| 1 | 51065007040 | raw water pump | 1 |
| 2 | 51065050072 | drive shaft raw water pump | 1 |
| 3 | 51965010407 | radial shaft seal 20X47X7-NB | 1 |
| 4 | 06290200128 | circlip 47X1,75-ZNPHR5F | 1 |
| 5 | 51934100015 | ball bearing 6204-2RSRZ27YC3 | 1 |
| 6 | 51065200056 | Axial face seal | 1 |
| 7 | 51908010075 | lock washer | 2 |
| 8 | 51065060082 | Impeller | 3 |
| 9 | 51069010093 | Coolant pump seal | 3 |
| 9 | 51069010094 | Coolant pump seal | 2 |
| 10 | 51065200055 | Axial face seal | 1 |
| 11 | 06314600402 | ball bearing 6303-ZC3 | 1 |
| 12 | 51908010076 | lock washer | 1 |
| 13 | 51069010191 | Coolant pump seal | 1 |
| 14 | 51960020061 | plug 9,2X5,5-14-PE-NF | 1 |
| — | 51981250003 | drain valve raw water pump | 1 |
| — | 06842520115 | flange BA30X53-2 | 2 |
| — | 06562562504 | gasket 30X53X1,5-AFQ1-M3219 | 2 |
